horizontal sachet packing machine for liquid&sauce horizontale Verpackungsmaschine fuer Flüssigkeit

Horizontal sachet packaging machine for liquid&sauce horizontale Verpackungsmaschine fuer Flüssigkeit und Sauce designed and manufactured by our engineer teams in cosmetic&food&pharma making and packaging machinery is widely used in the daily chemical industry like packaging machinery as well as the filling machine in various industries.We PENGLAI INDUSTRIAL CORPORATION moreover can design and produce the packaging machine according to the special requirements from customers.
Feature of horizontal sachet packing machine for liquid&sauce:
1. Versatility strong, one machinery can be realized powder, liquid, granules, paste different types of packaging materials.

2. Mainframe Frequency Conversion System: Imported AC motor and frequency conversion, stable and reliable operation; Low speed and large torque ensure excellent performance even under sharp fluctuations of load.
3. Servo Blanking System: Servo motor controls rotation of blanking bolt directly by pulse number; Stable and reliable performance, convenience of regulation.
4. Package Making System: The package making and sealing and filling systems are independent to each other in this system. The two systems are linked and coordinated by mechanical coupling and programmable logic controller (PLC). Therefore, the system is suitable for a variety of products and sizes of package.
5. Finished Product Sealing System: Fully automatic production facility that finishes package making, metering, filling, sealing and other packaging processes by heat-sealing packaging material (polyethylene membrane, multilayer composite membrane etc. ). The package shall be three-side or four-side sealed flat package. Fillers of different types may package a variety of products.
6. Integrated Control System: It is composed of PLC, frequency converter etc., featuring a high level of integration, strong control capabilities and high reliability of operation. Touch screen technology eases and facilities operation. The optoelectric transducer, encoder, proximity switch etc. Are all equipped with imported and advanced sensing elements, so the mechanical and electricalintegration of the entire frame is embodied perfectly.

Technical Parameter of horizontal packing machine with mixing hopper:
Pouch Width 65mm-140mm Pouch Length 70mm-180mm
Pouch Type 3 Side Sealing or 4 Side Sealing
Max Volume 160ml Speed 40-80 pouch/min
Packaging Film: Complex Film
Accuracy less than ± 1.5% Reel 400mm
Electricity Consumption 3.5KW
Air Consumption 0.7m3/min Weight 750KG
Size(L*W*H) 2500mm*940mm*1370mm

PENGLAI since 1992 has been manufacturing the cosmetic&food making and packaging machinery.In these field we have the experience rich enough to solve the questions encountered by our customers from both home and abroad.For more information about high quality machinery like the horizontal packing machine,please email via jackdu999@yahoo.com or browse our website www.cosmeticsmachinery.blogspot.com plus http://youtube.com/user/mrjackdu007
Follow us on twitter:http://www.twitter.com/jackdu007
Like us on facebook:http://www.facebook.com/jackdu999
Skype us by :turnanewleaf

PENGLAI INDUSTRIAL CORPORATION LIMITED

Semi automatic Rotary capping machine Máquina Llenadora de Líquidos Semiautomatica

Rotary capping machine with Round turntable&tam otomatik vidalı paketleme makinesi

designed and manufactured by PENGLAI cosmetic&food&pharma making and packaging machinery is widely used in the daily chemical industry like the screw packaging process/rivet packing and such like.We as a famous manufacturer moreover can design and produce the packaging machine according to the special requirements from customers.
Product Characteristics and Field of Application:
It is widely used in packaging beverage such as yogurt and juice etc.
It is suitable for small amount and various requirement of medium and small food processing or chemical industry etc.

Function: automatic cup-falling, automatic date-coding , automatic sealing, automatic cup-ejecting, automatic output in row etc.
Its automation part adopts the PLC system from Japan and Human Machine Interface, with stable performance.
Each procedure is controled by microcomputer and adjust in the Human Machine Interface. With less procedures , easy operation, there is no need to specially train the operating staff.
Adopting the curve transmitting principle, makes it stable in performance and easy in operation .
Adopting aluminium alloy rust-proof treatment, it is safe and sanitary.
With small dimension, occupies less space.
Both its body and frame being made of stainless steel SUS#304 with the technology of laser cutting and shape by CNC at one time, it is beautiful, solid and durable.

Designed with idler wheel and holder, it is convenient in move and easy in installation.
It is stable in operation, with less noisy and lower consumption.
Meeting the requirement of GMP.
With scientific and compact design, good in sealing, beautiful in appearance and durable in use as well as good in cost performance, it is the first choice for packaging food.
With reliable quality , provide one-year maintenance for free and lifelong maintenance.
Special research for equipments, manufacturing experience and considerate after -sale service will make you satisfactory
Standard Configuration
1. Intelligentized programmable Control System 9. Automatic Sealing Device
2. Chinese and English Interface with humanized control system 10. Automatic Fillm-collecting Device
3. Automatic Temperature Control and Compensating System 11. Atomatic Output in Row Device
4. Automatic Acousto-optic Alarming System 5、Automatic Cup-falling Device
6. Automatic Cup-falling Photoelectric Detection Device 7.Automatic Film-conveying Device 8. Automatic Film Picture Position Device
Selective Configuration
1. Automatic Date-coding Machine2、Automatic Fill Machine
Applicable Product beverage such as yogurt and juice etc.
Packaging Material Plastic Compound Film（PE 、PP、Easy-open Film and so on）
Sealing Type Heat Sealing
Product Model YX-03
Power Supply（V/HZ） 220/50/60 Power Consumption（W） 800
Sealing Range (mm) 80*120 Or∮＜80
Machine Dimension(L*W*H)(mm) 1000*800*1650 Capacity(PCS/HR) 1000-1200

SHENZHEN PENGLAI since 1992 has been manufacturing the cosmetic&food making and packaging machinery.In these field we have the experience rich enough to solve the questions encountered by our customers from both home and abroad.For more information about PENGLAI machinery like rotary capping machine with turntable,please email via jackdu999@yahoo.com or browse our website www.cosmeticsmachinery.blogspot.com plus http://youtube.com/user/mrjackdu007
Follow us on twitter:http://www.twitter.com/jackdu007
Like us on facebook:http://www.facebook.com/jackdu999
Skype us by :turnanewleaf

PENGLAI INDUSTRIAL CORPORATION LIMITED

honey jam juice jelly cups forming filling sealing machine tasses de remplissage machine à sceller

honey jam juice jelly cups forming filling sealing machine tasses de remplissage machine à sceller

designed and manufactured by our engineer team in cosmetic&food&pharma making and packaging machinery is widely used in the daily chemical industry like honey jam juice jelly cups forming filling sealing machine tasses de remplissage machine à sceller and such like.We as a famous manufacturer moreover can design and produce the packaging machine according to the special requirements from customers.
This series honey jam juice jelly cups forming filling sealing machine tasses de remplissage machine à sceller is made of stainless steel and is designed to meet the need to fill drinks into plastic bottles and cups .

Automatically finish the processes of falling cups, filling, sealing, date printing, cutting the edge, photoelectric tracking and sterilizing with ultraviotet lay.

It is mainly used in the industries like: soya-bean milk,milk,fruit juice,mineral water and so on.
Technical Specifications of cup filling and sealing machine
Model YX-60A-4
Power 220V3.5KW
Capacity 3600cups/hour
Filling Range 50-500ml
Temperature 0-300°C
Seal Material PE PP PE/PET
Air Consumption 0.4m3/min 8bar
Overall Dimension 200×70×155cm
Weight 500Kg

Our Factory since 1992 has been manufacturing the cosmetic&food making and packaging machinery.In these field we have the experience rich enough to solve the questions encountered by our customers from both home and abroad.For more information about various high quality machinery like honey jam juice jelly cups forming filling sealing machine tasses de remplissage machine à sceller,please email via jackdu999@yahoo.com or browse our website http://penglaichina.com.
Follow us on twitter:http://www.twitter.com/jackdu007
Like us on facebook:http://www.facebook.com/jackdu999
Skype us by :turnanewleaf
Call us via:0086-15811882441

PENGLAI INDUSTRIAL CORPORATION LIMTED

full automatic rotary cup filling sealing capping machine llenado tapado automático de la máquina

YX-900 type fully automatic rotary filling sealing calling machine for plastic ( paper ) cup is suitable for various yogurt, milk, soy milk, fruit juice beverages, seasoning, jam, tofu and other products of the production
 Working process
Can automatically complete the plastic ( paper ) cup automatic falling, filling, date printing, photoelectric positioning, sealing, automatic core cutting and waste film recycling and other functions.
Equipments:

The capping machine adopts Japan OMRON Programmable logic controller, Taiwan pneumatic control components, intelligent digital display temperature control system .With high sealing strength, good sealing performance, low failure rate, occupy small area and other features.
Technical specification
Model  YX-900
Capacity 900 cup/hour Filling range  10ml～300ml(adjust)
Heat power 1 KW Air consumption  0.6 m3/min
Voltage  220V   50Hz Weight   250kg
Material  Stainless steel  Overall dimension 1250mm*1250mm*1750mm
Package Wooden case

PENGLAI has been manufacturing the cosmetic&food making and packaging machinery.In these field we have the experience rich enough to solve the questions encountered by our customers from both home and abroad.For more information about HIGH QUALITY machinery like ratory filling sealing machine fully automatic model,please email via jackdu999@yahoo.com or browse our website www.cosmeticsmachinery.blogspot.com plus http://penglaichina.com
Follow us on twitter:http://www.twitter.com/jackdu007
Like us on facebook:http://www.facebook.com/jackdu999
Skype us by :turnanewleaf

PENGLAI INDUSTRIAL CORPORATION LIMITED

automatic Glass bottle filling vacuum capping machine Vakuum-Verschließmaschine

Full automatic Glass bottle filling rotary vacuum capping machine for a food packaging line Vakuum-Verschließmaschine
